Basic Parameters

Specification: 2-7 core

Shell: zinc alloy. Nickel plated

Knurled nut: zinc alloy. Nickel plated

Contactor: Copper. Silver plated

Insulator: Gum wood core

Plug and Socket Connection: Screwed

Installation Diameter: 12mm

Installation method: thread screwing

Environmental conditions

Ambient temperature: -40°C to +105°C

Atmospheric pressure: up to 4.4kpa

Vibration: frequency of 10-100Hz, acceleration up to 100m/s2

Shock: frequency of 60-80 times / min, acceleration up to 250m / s2

Centrifugal: acceleration up to 250m/s2

Main technical characteristics

Rated voltage: 300V

Rated current: 5A

Contact resistance: not more than 0.005Ω

Insulation resistance: not less than 500MΩ under normal conditions, not less than 20MΩ after constant temperature and heat.

Waterproof rating: IP67
